CSE-4/562 Spring 2021 - Indexing


CSE-4/562 Spring 2021

March 2, 2021

Garcia-Molina/Ullman/Widom: Ch. 8.3-8.4, 14.1-14.2, 14.4


Leveraging Organization

$150 $50
No Index
ToC Summary

Today's Focus

$\sigma_C(R)$ and $(\ldots \bowtie_C R)$

(Finding records in a table really fast)

$\sigma_{R.A = 7}(R)$

Where is the data for key 7?

Option 1: Linear search

$O(N)$ IOs

Initial Assumptions

Data is sorted on an attribute of interest (R.A)

Updates are not relevant

Option 2: Binary Search

$O(\log_2 N)$ IOs

Better, but still not ideal.

Idea: Precompute several layers of the decision tree and store them together.

Fence Pointers

... but what if we need more than one page?

Add more indirection!

ISAM Trees

Which of the following is better?

Worst-Case Tree?

$O(N)$ with the tree laid out left/right-deep

Best-Case Tree?

$O(\log N)$ with the tree perfectly balanced

It's important that the trees be balanced

... but what if we need to update the tree?


  • Finding space for new records
  • Keeping the tree balanced as new records are added

Idea 1: Reserve space for new records

Just maintaining open space won't work forever...

Rules of B+Trees

Keep space open for insertions in inner/data nodes.
‘Split’ nodes when they’re full
Avoid under-using space
‘Merge’ nodes when they’re under-filled

Maintain Invariant: All Nodes ≥ 50% Full

(Exception: The Root)

Deletions reverse this process (at 50% fill).

Incorporating Trees into Queries

$\sigma_C(R)$ and $(\ldots \bowtie_C R)$

Original Query: $\pi_A\left(\sigma_{B = 1 \wedge C < 3}(R)\right)$

Possible Implementations:

$\pi_A\left(\sigma_{B = 1 \wedge C < 3}(R)\right)$
Always works... but slow
$\pi_A\left(\sigma_{B = 1}( IndexScan(R,\;C < 3) ) \right)$
Requires a non-hash index on $C$
$\pi_A\left(\sigma_{C < 3}( IndexScan(R,\;B=1) ) \right)$
Requires a any index on $B$
$\pi_A\left( IndexScan(R,\;B = 1, C < 3) \right)$
Requires any index on $(B, C)$

Lexical Sort (Non-Hash Only)

Sort data on $(A, B, C, \ldots)$

First sort on $A$, $B$ is a tiebreaker for $A$,
$C$ is a tiebreaker for $B$, etc...

All of the $A$ values are adjacent.
Supports $\sigma_{A = a}$ or $\sigma_{A \geq b}$
For a specific $A$, all of the $B$ values are adjacent
Supports $\sigma_{A = a \wedge B = b}$ or $\sigma_{A = a \wedge B \geq b}$
For a specific $(A,B)$, all of the $C$ values are adjacent
Supports $\sigma_{A = a \wedge B = b \wedge C = c}$ or $\sigma_{A = a \wedge B = b \wedge C \geq c}$

For a query $\sigma_{c_1 \wedge \ldots \wedge c_N}(R)$

  1. For every $c_i \equiv (A = a)$: Do you have any index on $A$?
  2. For every $c_i \in \{\; (A \geq a), (A > a), (A \leq a), (A < a)\;\}$: Do you have a tree index on $A$?
  3. For every $c_i, c_j$, do you have an appropriate index?
  4. A simple table scan is also an option

Which one do we pick?

(You need to know the cost of each plan)

These are called "Access Paths"

Strategies for Implementing $(\ldots \bowtie_{c} S)$

Sort/Merge Join
Sort all of the data upfront, then scan over both sides.
In-Memory Index Join (1-pass Hash; Hash Join)
Build an in-memory index on one table, scan the other.
Partition Join (2-pass Hash; External Hash Join)
Partition both sides so that tuples don't join across partitions.
Index Nested Loop Join
Use an existing index instead of building one.

Index Nested Loop Join

To compute $R \bowtie_{S.B > R.A} S$ with an index on $S.B$
  1. Read one row of $R$
  2. Get the value of $a = R.A$
  3. Start index scan on $S.B > a$
  4. Return all rows from the index scan
  5. Read the next row of $R$ and repeat

Index Nested Loop Join

To compute $R \bowtie_{S.B\;[\theta]\;R.A} S$ with an index on $S.B$
  1. Read one row of $R$
  2. Get the value of $a = R.A$
  3. Start index scan on $S.B\;[\theta]\;a$
  4. Return all rows from the index scan
  5. Read the next row of $R$ and repeat

What if we need multiple sort orders?

Data Organization

Data Organization

Data Organization

Unordered Heap
$O(N)$ reads.
Sorted List
$O(\log_2 N)$ random reads for some queries.
Clustered (Primary) Index
$O(\ll N)$ sequential reads for some queries.
(Secondary) Index
$O(\ll N)$ random reads for some queries.

Hash Indexes

A hash function $h(k)$ is ...

... deterministic
The same $k$ always produces the same hash value.
... (pseudo-)random
Different $k$s are unlikely to have the same hash value.

$h(k)\mod N$ gives you a random number in $[0, N)$


$N$ is too small
Too many overflow pages (slower reads).
$N$ is too big
Too many normal pages (wasted space).

Idea: Resize the structure as needed

To keep things simple, let's use $$h(k) = k$$

(you wouldn't actually do this in practice)

Changing hash functions reallocates everything randomly

Need to keep the entire source and hash table in memory!

$$h(k) \mod N$$ vs $$h(h) \mod 2N$$

if $h(k) = x \mod N$


$h(k) = $ either $x$ or $2x \mod 2N$

Each key is moved (or not) to precisely one of two buckets in the resized hash table.

Never need more than 3 pages in memory at once.

Changing sizes still requires reading everything!

Idea: Only redistribute buckets that are too big

Add a directory (a level of indirection)

  • $N$ hash buckets = $N$ directory entries
    (but $\leq N$ actual pages)
  • Directory entries point to actual pages on disk.
  • Multiple directory entries can point to the same page.
  • When a page fills up, it (and its directory entries) split.

Dynamic Hashing

  • Add a level of indirection (Directory).
  • A data page $i$ can store data with $h(k)%2^n=i$ for any $n$.
  • Double the size of the directory (almost free) by duplicating existing entries.
  • When bucket $i$ fills up, split on the next power of 2.
  • Can also merge buckets/halve the directory size.

Next time: LSM Trees and CDF-Indexing
